SpainSH0512 Disposable Pressure Transducer
SH0512 Disposable Pressure Transducer
Previous: SHA04 Anesthetic Products
Next: SH060901 Dental Needle
Product Description
Disposable Pressure Transducer
Disposable Pressure Transducer is made of medical PC and PVC material
Operating Parameters：
Operating Pressure Range : -30mmHg ~ +300mmHg
Operating Temperature Range : 15℃~ 40℃
Storage Range : -25℃ ~ +70℃
Atmosphere Pressure Range : 56 . 7kPa~ 113kPa
Zero Output : ± 25mmHg
Sensitivity : 5 μV/V/mmHg ± 2 %
Input Impedance : 1200Ω ~ 3200Ω
Output Impedance : 285Ω~ 315Ω
Zero Thermal Drift : ±0 . 3mmHg /℃
Zero Drift ：≤2mmHg
Natural Frequency : 40Hz nominal for a standard kit > 200Hz for transducer alone
Sensitivity Thermal Drift : ±0 . 1 % /℃
Leak Current : < 2 μA at 230VRMS 50Hz
Note : rated voltage 6 . 00VDC ; ambient temperature 25 ℃
Specification :
130cm pressure tubing with M / F connector 1piece
30cm pressure tubing with M / F connector 1piece
Disopsable pressure transducer 1piece
Flush device 3 cc / h ( 30cc / h ) 1piece
Male non-vented Cap 2piece
150cm single IV set 1piece
3-way stopcock 2piece
Disposable Pressure Transducer is made of medical PC and PVC material
Operating Parameters：
Operating Pressure Range : -30mmHg ~ +300mmHg
Operating Temperature Range : 15℃~ 40℃
Storage Range : -25℃ ~ +70℃
Atmosphere Pressure Range : 56 . 7kPa~ 113kPa
Zero Output : ± 25mmHg
Sensitivity : 5 μV/V/mmHg ± 2 %
Input Impedance : 1200Ω ~ 3200Ω
Output Impedance : 285Ω~ 315Ω
Zero Thermal Drift : ±0 . 3mmHg /℃
Zero Drift ：≤2mmHg
Natural Frequency : 40Hz nominal for a standard kit > 200Hz for transducer alone
Sensitivity Thermal Drift : ±0 . 1 % /℃
Leak Current : < 2 μA at 230VRMS 50Hz
Note : rated voltage 6 . 00VDC ; ambient temperature 25 ℃
Specification :
130cm pressure tubing with M / F connector 1piece
30cm pressure tubing with M / F connector 1piece
Disopsable pressure transducer 1piece
Flush device 3 cc / h ( 30cc / h ) 1piece
Male non-vented Cap 2piece
150cm single IV set 1piece
3-way stopcock 2piece
